Laser Marking
Laser Marking

Laser Marking

Electronic industrial, electrommunication,Auto parts, metals, watches and other metal or nonmetal products but not highly reflective meterials

Most Affordable

● Electro-optic conversion efficiency can reach up to 30%,the power consumption of machine is less than 500watt,it is the 1/10 of lamp pumped solid laser marking machine,save energy.

Free Maintenance

● Laser without any maintenance,also need not adjust or clean lens.

Long Use Life

● Equiped with quality laser device ,Long use life up to 100000 hours.

Fast Processing Speed

● The Processing speed is 2 times or 3 times faster than tranditional laser marking machine.

LMW30 Specification :

Model

LMW30

Maximum processing range

170mm * 170mm

Focal length

295mm

Minimum character

0.15mm

Minimum line width

0.01mm

Engraving Speed

800 standard characters/s

Wavelength

1064mm

Laser power

10%~100%(adjustable)

Laser Frequenc

20KHZ~200KHZ(adjustable)

Laser cooling

Cooling Fan

Environment Temperature

15℃-25℃

Power supply

AC220V/50HZ Max 500W

Engraving depth

<1.2mm

Weight

80KG

Dimension

1100 x 700 x1450
